ATIS 0600421.2001(S2015)

In-Line Filter for Use with Voiceband Terminal Equipment Operating on the Same Wire Pair with High Frequency (up to 12 MHz) Devices (formerly T1.421-2001 (R2006) )

The Alliance for Telecommunications Industry Solutions , 12/01/2001

Publisher: ATIS

File Format: PDF

$87.00$175.00

Description

Standard By:The Alliance for Telecommunications Industry Solutions , 12/01/2001

Published:12/01/2001

Pages:45

File Size:1 file , 1.2 MB

Language:English

Note:This product is restricted and cannot be purchased in the following countries Ukraine, Russia, Belarus

This standard presents the electrical and physical characteristics of an In-Line filter (initially, and sometimes still, called a micro-filter), that is used to protect voiceband premises equipment from the high frequencies of digital data over voice services in the 25 kHz to 12 MHz range. It is also used to protect data over voice services from impedance changes and other detrimental impairments caused by voiceband equipment. Applications such as alarm systems and series stacking are beyond the scope of this standard.

ATIS 0600421.2001(S2015)

In-Line Filter for Use with Voiceband Terminal Equipment Operating on the Same Wire Pair with High Frequency (up to 12 MHz) Devices (formerly T1.421-2001 (R2006) )
