BS PD IEC TS 62196-3-1:2020

Plugs, socket-outlets, vehicle connectors and vehicle inlets. Conductive charging of electric vehicles-Vehicle connector, vehicle inlet and cable assembly for DC charging intended to be used with a thermal management system

BSI Group , 03/31/2020

Publisher: BS

File Format: PDF

$184.00$368.30

Description

Standard By:BSI Group , 03/31/2020

Published:03/31/2020

Pages:66

ISBN(s):9780580981630

File Size:1 file , 3.7 MB

Language:English

Note:This product is unavailable in Ukraine, Russia, Belarus

This document applies to accessories and cable assemblies with the same configuration as specified in IEC 62196-3:2014 with rated operating voltage not exceeding 1 500 V DC and a rated current not exceeding 500 A that employ

— thermal sensing, or— thermal transport and thermal sensing

with the system architecture described in 4.101.

These accessories and cable assemblies are intended to be used in conductive charging systems for circuits specified in IEC 61851-23.Cross References:IEC 62196-1:2014ISO 2719:2016ISO 25178-1:2016IEC 62196-2:2016IEC 60364-5-54:2011ISO 17409:2020IEC 62196-3:2014 IEC 62893-4-1IEC 60811-501IEC 61851-23IEC 62893-1:2017 IEC 62893-2:2017IEC 62893-4-2IEC 61851-24
