IEEE 802.3ca-2020

IEEE 802.3ca-2020 PDF

The scope of this project is to amend IEEE Std 802.3 to add physical layer specifications and management parameters for point-to-multipoint passive optical networks supporting MAC data rates of 25 Gb/s or 50 Gb/s in the downstream direction and 10 Gb/s, 25 Gb/s, or 50 Gb/s in the upstream direction, with distance and split ratios consistent with those defined in IEEE Std 802.3. It also extends the operation of Ethernet Passive Optical Networks (EPON) protocols, such as MultiPoint Control Protocol (MPCP) and Operation Administration and Management (OAM). Amendment Standard - Superseded. This amendment to IEEE Std 802.3-2018 extends the operation of Ethernet passive optical networks (EPONs) to multiple channels of 25 Gb/s providing both symmetric and asymmetric operation for the following data rates downstream/upstream): 25/10 Gb/s, 25/25 Gb/s, 50/10 Gb/s, 50/25 Gb/s, and 50/50 Gb/s. This standard specifies the 25 Gb/s EPON Multi-Channel Reconciliation Sublayer (MCRS), Nx25G-EPON Physical Coding Sublayers (PCSs), Physical Media Attachment (PMA) sublayers, and Physical Medium Dependent (PMD) sublayers that support both symmetric and asymmetric data rates while maintaining backward compatibility with already deployed 10 Gb/s EPON equipment. Backward compatibility with deployed 1G-EPON and ITU-T G.984 GPON is maintained with 25GBASE-PQ for the specific case of 1G-EPON and GPON ONUs using reduced-band (40 nm) lasers. The EPON operation is defined for distances of at least 20 km, and for a split ratio of at least 1:32.
