SAE ARP7503

Methods of Shield Termination for Two-Piece, Crimp-Style Ferrule on Shielded Cables

SAE International , 11/03/2020

Publisher: SAE

File Format: PDF

$50.00$101.00

Description

Standard By:SAE International , 11/03/2020

Published:11/03/2020

File Size:1 file , 740 KB

Language:English

Note:This product is unavailable in Ukraine, Russia, Belarus

AS21608 shield terminating, crimp-style ferrule applications on shielded cables require various piece parts in multiple combinations to ground the shield of non-environmental cables. This ARP provides the recommended methods to ensure the shield ground wire is terminated correctly and the shield is protected. Refer to AS83519 for shield grounding when eviornmental resistance is required.
