SAE J3218_202209

Definition and Measurement of Beam Axle Efficiency

SAE International , 09/14/2022

Publisher: SAE

File Format: PDF

$60.00$120.00

Description

Standard By:SAE International , 09/14/2022

Published:09/14/2022

Pages:23

File Size:1 file , 860 KB

Language:English

Note:This product is unavailable in Ukraine, Russia, Belarus

This SAE Recommended Practice covers beam axles utilizing hypoid gear final drives. It is a component level test, performed with three dynamometers in a “T-cell” arrangement. It includes both an efficiency characterization method, as well as a break-in method to support efficiency characterization. It was developed for beam axles used in light truck applications but may be extended to other hypoid gear drive systems.
