AIA NAS955

Perforated tape with variable block format as described in the following sections shall be usable, interchangeably, among numerically controlled machines which conform to the same format classification as shown in Appendix A. (Note: The degree of interchangeability will depend upon the conformity of the machines with respect to function, capacity, range, horsepower, geometric relationship of axes, preparatory, miscellaneous and tooling functions and use of absolute or incremental dimensions.)

Purpose

This specification is intended to serve as a guide in the coordination of system design to minimize the variety of program manuscripts required, to promote uniformity of programming techniques, and to foster interchangeability of input tapes between numerically controlled machines of the same classification by type, process function, size, and accuracy. It is intended that simple numerically controlled machines-be programmed using a simple format which is systematically extensible for more complex machines.

Classification

This standard applies wherever variable block format is used on perforated tape to control numerically controlled machines. (Note: This format will usually be used with tape read row-by-row.)

Class III

Positioning and straight cut numerically controlled machine/controller.

Class IV

Continuous path or contouring/positioning numerically controlled machine/controller.
