BS 7870-4.11:2011+A1:2016

LV and MV polymeric insulated cables for use by distribution and generation utilities-Specification for distribution cables with extruded insulation for rated voltages of 11 kV and 33 kV-Single-core 33 kV lead sheathed cables (Implementation of HD 620)

BSI Group , 06/30/2016

Publisher: BS

File Format: PDF

$132.00$264.16

Description

Standard By:BSI Group , 06/30/2016

Published:06/30/2016

Pages:26

ISBN(s):9780580938061

File Size:1 file , 1.4 MB

Language:English

Note:This product is unavailable in Ukraine, Russia, Belarus

BS 7870-4.11:2011+A1:2016 specifies requirements for the construction, dimensionsand mechanical and electrical properties of 19/33(36) kV single-core cableshaving either aluminium or copper conductors, cross-linked polyethylene (XLPE)extruded insulation, a lead alloy sheath and a medium density polyethylene(MDPE) oversheath.This section of BS 7870 is applicable to cables that are designed for a maximumcontinuous conductor operating temperature of 90 °C and for a maximumshort-circuit conductor temperature of 250 °C.NOTE Information to be supplied by the purchaser, and items to be agreedbetween the purchaser and the manufacturer at the time of enquiry and/or orderare given in Annex B. Guidance on type testing is given in Annex C.To be read in conjunction with BS 7870-1:2011,BS 7870-2:2011Cross References:BS 7870-1BS 7870-2BS EN 12548BS EN 60228:2005BS EN 60811-1-2BS EN 60811-1-3BS EN 60811-2-1HD 603 S1HD 605 S2HD 620 S2HD 626 S1HD 627 S1IEC 60502-2Incorporates the following:Corrigendum, August 2012. Amendment, June 2016. Amends and replaces BS 7870-4 .11:2011
