BS PD IEC/TS 62257-9-1:2016

BS PD IEC/TS 62257-9-1:2016 Decentralized Rural Electrification Systems (DRES) are designed to supply electric power forsites which are not connected to a large interconnected system, or a national grid, in order tomeet basic needs.The majority of these sites are:

• isolated dwellings;
• village houses;
• community services (public lighting, pumping, health centres, places of worship or culturalactivities, administrative buildings, etc.);
• economic activities (workshops, micro-industry, etc.).

The DRESs fall into the following three categories:

• process electrification systems (for example, for pumping);
• individual electrification systems (IES) for single users;
• collective electrification systems (CES) for multiple users.

Process or individual electrification systems exclusively consist of two subsystems:

• an electric energy generation subsystem;
• the user's electrical installation.

Collective electrification systems, however, consist of three subsystems:

• an electric energy generation subsystem;
• a distribution subsystem, also called microgrid;
• user's electrical installations including interface equipment between the installations andthe microgrid.

This technical specification applies to a micropower plant which is the electric energygeneration subsystem associated with a decentralized rural electrification system.It provides general requirements for the design, erection and operation of micropower plantsand general requirements to ensure the safety of persons and property.The micropower plants covered by this specification are low-voltage a.c., three-phase orsingle-phase, with rated capacity less than, or equal to, 100 kVA. The rated capacity is at theelectrical output of the micropower plant, that is, the upstream terminals of the main switchbetween the micropower plant and the microgrid. They do not include voltage transformation.Cross References:IEC 60364IEC 60364-5-53:2001IEC/TS 62257-2:2015IEC/TS 62257-4:2015IEC/TS 62257-5:2015IEC/TS 62257-6:2015IEC/TS 62257-7-1:2010IEC/TS 62257-7-3:2008IEC/TS 62257-9-2:2016sIEC/TS 62257-9-4:2016IEC 62548:2016IEC 60050-448:1995IEC 60050-811:1991 IEC 60050-826:2004IEC 60529IEC/TS 61201:2007IEC/TS 62257-1:2015IEC/TS 62257-3:2015IEC/TS 62257-8-1:2007IEC 62485-2
