IEC 60748-2-20 Ed. 2.0 b:2008

Semiconductor devices - Integrated circuits - Part 2-20: Digital integrated circuits - Family specification - Low voltage integrated circuits

International Electrotechnical Commission , 02/27/2008

Publisher: IEC

File Format: PDF

$95.00$190.00

Description

Standard By:International Electrotechnical Commission , 02/27/2008

Published:02/27/2008

Pages:41

File Size:1 file , 1000 KB

Language:English, French

Note:This product is unavailable in Ukraine, Russia, Belarus

Aims at giving DC interface specifications for various sets of values, where each comprises the nominal value of power supply voltage, its tolerance, and the worst-case limit values of the input and output voltages for low voltage integrated circuits. This second edition of IEC 60748-2-20 cancels and replaces the first edition published in 2000. This edition constitutes a technical revision. This edition includes the following significant changes with respect to the previous edition: - Expansion of power supply voltages down to nominal 1,0 V - Addition of Schmitt-trigger input specification
