IEC 61076-8-106 Ed. 1.0 b:2023

Connectors for electrical and electronic equipment – Product requirements – Part 8-106: Power connectors – Detail specification for 2-poles push-pull coupling rectangular connectors with fuses, for 400 V DC rated voltage and 16 A rated current

International Electrotechnical Commission , 07/01/2023

Publisher: IEC

File Format: PDF

$139.00$278.00

Description

Standard By:International Electrotechnical Commission , 07/01/2023

Published:07/01/2023

Pages:70

ISBN(s):9782832271254

File Size:1 file , 1.8 MB

Language:English, French

Note:This product is unavailable in Ukraine, Russia, Belarus

This part of IEC 61076-8 applies to free and fixed, 2-pole push-pull and snap locking power rectangular connectors with fuses, with rated voltage of 400 V DC and rated current of 16 A. It includes overall dimensions, interface dimensions, technical characteristics, performance requirements, and test methods.

Connectors according to this document are connectors with breaking capacity (CBC) according to IEC 61984 which are mainly used in DC power conduction, in the field of electrical and electronic equipment.

IEC 61076-8-106 Ed. 1.0 b:2023

Connectors for electrical and electronic equipment – Product requirements – Part 8-106: Power connectors – Detail specification for 2-poles push-pull coupling rectangular connectors with fuses, for 400 V DC rated voltage and 16 A rated current
