IEC 62153-4-7 Ed. 2.1 b:2018

Metallic communication cable test methods - Part 4-7: Electromagnetic compatibility (EMC) - Test method for measuring of transfer impedance Z_T and screening attenuation a_S or coupling attenuation a_C of connectors and assemblies up to and above 3 GHz - Triaxial tube i

International Electrotechnical Commission , 05/09/2018

Publisher: IEC

File Format: PDF

$221.00$443.00

Description

Standard By:International Electrotechnical Commission , 05/09/2018

Published:05/09/2018

Pages:180

File Size:1 file , 2.3 MB

Language:English, French

Note:This product is unavailable in Ukraine, Russia, Belarus

IEC 62153-4-7:2015+A1:2018 describes a triaxial method, suitable to determine the surface transfer impedance and/or screening attenuation and coupling attenuation of mated screened connectors (including the connection between cable and connector) and cable assemblies. This method could also be extended to determine the transfer impedance, coupling or screening attenuation of balanced or multipin connectors and multicore cable assemblies. For the measurement of transfer impedance and screening- or coupling attenuation, only one test set-up is needed. This edition includes the following significant technical changes with respect to the previous edition:
The document is revised and updated. The changes of the revised IEC 62153-4-3:2013, and IEC 62153-4-4:2015, are included. Measurements can be achieved now with mismatch at the generator site, impedance matching devices are not necessary. The contents of the corrigendum of April 2016 have been included in this copy. This consolidated version consists of the second edition (2015) and its amendment 1 (2018). Therefore, no need to order amendment in addition to this publication.
