IEC 62196-2 Ed. 2.0 b:2016

Plugs, socket-outlets, vehicle connectors and vehicle inlets - Conductive charging of electric vehicles - Part 2: Dimensional compatibility and interchangeability requirements for a.c. pin and contact-tube accessories

International Electrotechnical Commission , 02/18/2016

Publisher: IEC

File Format: PDF

$196.00$392.00

Description

Standard By:International Electrotechnical Commission , 02/18/2016

Published:02/18/2016

Pages:122

File Size:1 file , 4 MB

Language:English, French

Note:This product is unavailable in Ukraine, Russia, Belarus

IEC 62196-2:2016 applies to plugs, socket-outlets, vehicle connectors and vehicle inlets with pins and contact-tubes of standardized configurations, herein referred to as accessories. They have a nominal rated operating voltage not exceeding 480 V a.c., 50 Hz to 60 Hz, and a rated current not exceeding 63 A three-phase or 70 A single phase, for use in conductive charging of electric vehicles. This second edition cancels and replaces the first edition published in 2011 and constitutes a technical revision. This second edition includes the following significant technical changes with respect to the previous edition.
a) Standard sheets for configurations type 2 and type 3 have been updated.
b) Configuration type 2 is now available with optional shutter.
This publication is to be read in conjunction with IEC 62196-1:2014.
