IEC 62228-5 Ed. 1.0 b:2021

Integrated Circuits - EMC Evaluation Of Transceivers - Part 5: Ethernet Transceivers

International Electrotechnical Commission , 04/01/2021

Publisher: IEC

File Format: PDF

$227.00$455.00

Description

Standard By:International Electrotechnical Commission , 04/01/2021

Published:04/01/2021

Pages:228

ISBN(s):9782832210374

File Size:1 file , 25 MB

Language:English, French

Note:This product is unavailable in Ukraine, Russia, Belarus

This part of IEC 62228 specifies test and measurement methods for EMC evaluation of Ethernet transceiver ICs under network condition. It defines test configurations, test conditions, test signals, failure criteria, test procedures, test setups and test boards. It is applicable for transceiver of the Ethernet systems

- 100BASE-T1 according to ISO/IEC/IEEE 8802-3/AMD1;
- 100BASE-TX according to ISO/IEC/IEEE 8802-3;
- 1000BASE-T1 according to ISO/IEC/IEEE 8802-3/AMD4

and covers

- the emission of RF disturbances;
- the immunity against RF disturbances;
- the immunity against impulses;
- the immunity against electrostatic discharges (ESD).
