IEEE 1377-2012

IEEE 1377-2012 PDF

This standard defines a Table structure for utility application data to be passed between an End Device and any other device. It neither defines device design criteria nor specifies the language or protocol used to transport that data. The Tables defined in this standard represent a data structure that shall be used to transport the data, not necessarily the data storage format used inside the End Device. The Utility Industry has a need for a standard that provides an interoperable "plug-and-play" environment for field metering devices. The purpose of this standard is to define the framework and data structures for transporting Utility End Device data to and from End Devices and for use by enterprise systems. This standard is intended to accommodate the concept of an advanced metering infrastructure such as that identified by the Office of Electricity Delivery and Energy Reliability of the U.S. Department of Energy; the Smart Metering Initiative of the Ontario Ministry of Energy (Canada); and the stated requirements of Measurement Canada for the approval of a metering device for use in Canada. This standard is to provide a uniform, structured, and adaptive data model, such that Utility End Devices and ancillary devices (e.g., home appliances and communication technology) can operate in a "plug-and-play" and multisource enterprise Advanced Metering Infrastructure (AMI) environment. This standard extends the definitions provided by IEEE Std 1377-1997 to include provisions for enterprise-level asset management, data management, and uniform data exchange capability, through the use of common and managed Extensible Markup Language (XML)/Table Definition Language (TDL) and XML/Exchange Data Language (EDL) End Device Class models. Revision Standard - Inactive-Reserved. Common structures are provided in this standard for encoding data in communication between End Devices (meters, home appliances, IEEE 1703 Nodes) and Utility enterprise collection and control systems using binary codes and Extensible Markup Language (XML) content. The Advanced Metering Infrastructure (AMI) and SmartGrid requirements are addressed as identified by the Office of Electricity Delivery and Energy Reliability of the U.S. Department of Energy and by the Smart Metering Initiative of the Ontario Ministry of Energy (Canada) and of Measurement Canada. Sets of tables are exposed that are grouped together into sections that pertain to a particular feature-set and related function such as Time-of-use, Load Profile, Security, Power Quality, and more. Each standard Table Set (Data Model) can be expanded or restricted by the Manufacturer of the IEEE 1377 Device or home appliance using XML/TDL descriptive registered syntax (XML-based Table Definition Language) and enterprise data-value management using EDL (Exchange Data Language) in a manner that is machine readable. Published jointly with NEMA and Measurement Canada, Tables are provided in support of Gas, Water, and Electric sensors and related appliances. Tables are also provided for network configuration and management by referencing its companion standard IEEE Std 1703TM-2012. IEEE Std 1377-2012 is co-published as ANSI C12.19 and MC12.19.
