SAE AIR4465A

Design and Handling Guide Radio Frequency Absorptive Type Wire and Cables (Filter Line, AS85485)

SAE International , 01/31/2020

Publisher: SAE

File Format: PDF

$70.00$141.00

Description

Standard By:SAE International , 01/31/2020

Published:01/31/2020

Pages:41

File Size:1 file , 1.5 MB

Language:English

Note:This product is unavailable in Ukraine, Russia, Belarus

This document presents design and application information which will allow optimized utilization of filter line wire and cable purchased to AS85485. Filter line wire is defined and design information is presented. The electrical and mechanical performance characteristics of the wire, along with recommended harnessing methods and techniques, are also presented.
