SAE ARP1233B

Gland Design Criteria and Dimensions for Dynamic Radial O-Ring Seal Applications Specifically for Engine and Engine Control Systems Operating at 1500 psi Max

SAE International , 04/14/2021

Publisher: SAE

File Format: PDF

$57.00$115.00

Description

Standard By:SAE International , 04/14/2021

Published:04/14/2021

File Size:1 file , 660 KB

Language:English

Note:This product is unavailable in Ukraine, Russia, Belarus

This document recommends standard gland design criteria and dimensions for dynamic radial O-ring seal applications specifically for engine and engine control systems operating at pressures up to a maximum of 1500 psi (10342.14 kPa) and provides recommendations for modifying these glands in special applications. There are no provisions in this document for anti-extrusion devices.

NOTE: The criteria set forth here are similar to but not identical with those in MIL-G-5514 and AS4716. This document is not intended to replace MIL-G-5514 or AS4716 for hydraulic applications.
