SAE J2490_201905

SAE No. 2 Friction Test Machine μPVT Test

SAE International , 05/31/2019

Publisher: SAE

File Format: PDF

$58.00$117.00

Description

Standard By:SAE International , 05/31/2019

Published:05/31/2019

Pages:21

File Size:1 file , 1 MB

Language:English

Note:This product is unavailable in Ukraine, Russia, Belarus

This SAE Recommended Practice is intended as the definition of a standard test, which may be subject to frequent change to keep pace with experience and technical advances. This should be kept in mind when considering its use.

The SAE No. 2 Friction Test Machine is used to evaluate the friction characteristics of automatic transmission plate clutches with automotive transmission fluids. It can also be used to conduct durability tests on wet friction systems.

The specific purpose of this document is to define a ¿¿PVT Test for the evaluation of the variation of wet friction system performance as a function of speed, temperature, and pressure. This procedure is intended as a standard for both suppliers and end users.

The only variables selected by the supplier or user of the friction system are:

a
Friction material
b
Fluid
c
Reaction plates

These three variables must be clearly identified when reporting the results of this test. If any of the test parameters or system hardware as described in this document are changed, other than the friction material, test fluid, or reaction plates, the data may not be reported as having been obtained using this document.

This procedure is intended to evaluate the endpoint/midpoint ratios, midpoint and breakaway coefficients. The procedure can be used to demonstrate changes that occur between the different levels of engagement speed, sump temperature, and apply pressure. Refer to SAE J2487, SAE J2488, or SAE J2489 for coefficient variations due to changes in power level.
