SAE MAP3440A

O-Ring Groove Design for Metric O-Ring Seals Used in Static Radial Compression Applications Specifically for Engine and Engine Control Systems

SAE International , 11/09/2021

Publisher: SAE

File Format: PDF

$65.00$130.00

Description

Standard By:SAE International , 11/09/2021

Published:11/09/2021

File Size:1 file , 640 KB

Language:English

Note:This product is unavailable in Ukraine, Russia, Belarus

This SAE Recommended Practice provides the design criteria for static elastomeric O-ring seals used specifically in engine and engine control systems. It provides radial compression groove dimensions for aerospace metric O-ring sizes specified in MA2010. The conditions considered to formulate the design criteria are also described, e.g., seal stretch, cross-section reduction, seal squeeze, and swell.
