IEC 60317-68 Ed. 1.1 b:2019

Specifications for particular types of winding wires - Part 68: Polyvinyl acetal enamelled rectangular aluminium wire, class 120 CONSOLIDATED EDITION

International Electrotechnical Commission , 06/12/2019

Publisher: IEC

File Format: PDF

$41.00$82.00

Description

Standard By:International Electrotechnical Commission , 06/12/2019

Published:06/12/2019

Pages:40

File Size:1 file , 1.1 MB

Language:English, French

Note:This product is unavailable in Ukraine, Russia, Belarus

IEC 60317-68:2017+A1:2019 specifies the requirements of enamelled rectangular aluminium winding wire of class 120 with a sole coating based on polyvinyl acetal resin, which may be modified providing it retains the chemical identity of the original resin and meets all specified wire requirements. The range of nominal conductor dimensions covered by this standard is

Width: minimum 2,0 mm and maximum 16,0 mm
Thickness: minimum 0,80 mm and maximum 5,60 mm
