IEC 62137-1-2 Ed. 1.0 b:2008

Surface mounting technology - Environmental and endurance test methods for surface mount solder joint - Part 1-2: Shear strength test

International Electrotechnical Commission , 05/14/2008

Publisher: IEC

File Format: PDF

$43.00$87.00

Description

Standard By:International Electrotechnical Commission , 05/14/2008

Published:05/14/2008

Pages:33

File Size:1 file , 1000 KB

Language:English, French

Note:This product is unavailable in Ukraine, Russia, Belarus

The test method described in IEC 62137-1-2:2007 is applicable to leadless surface mounting components and surface mounting connectors to which pull test is not applicable. It is not applicable to multi-lead components and gull-wing leads. The method is designed to test and evaluate the endurance of the solder joint between component terminals and lands on a substrate, by means of a shear type mechanical stress. This test is applicable to evaluate the effects of repeated temperature change on the strength of the solder joints between terminals and lands on a substrate.
